Features of the NL-SB42 Soundbar: Two-way design with a 3.5-inch woofer and a 0.75-inch tweeter Power over Ethernet (PoE) enables power, audio, and control over a single cable Supports both horizontal and vertical mounting orientations Programmable RGB light bar for status indication Consistent tonal characteristics across the NL Series for flexible deployment Seamless integration and management via Q-SYS Designer Software and Q-SYS Reflect Enterprise Manager Intrinsic Correction™ voicings applied automatically by Q-SYS to simplify tuning Includes a quick-install wall bracket with 3 cm of fine adjustment for easy installation Optional rubber feet available for shelf, table, or credenza mounting Specifications: Loudspeaker Type: Network PoE soundbar for Q-SYS LF Transducer: 3.5-inch (88.9 mm) paper cone woofer HF Transducer: 0.75-inch (19.05 mm) silk dome tweeter Effective Frequency Range: 110 Hz to 20 kHz Rated Noise Power: 12 W (PoE), 24 W (PoE ) Rated Coverage (-6 dB): 150° horizontal, 160° vertical (1 kHz – 10 kHz) Directivity Factor (Q): 2.7 Directivity Index (DI): 4.2 dB Maximum Continuous SPL: 90 dB (PoE), 93 dB (PoE ) Maximum Peak SPL: 106 dB (PoE), 107 dB (PoE ) Input Connector Type: RJ45 Enclosure Material: ABS Grille Material: Powder-coated steel Dimensions (H x W x D): 3.97 x 20.4 x 2.87 inches (101 x 518 x 73 mm) Net Weight: 3.86 lbs (1.75 kg) Operating Environment: Designed for indoor use Operating Temperature Range: 10° to 40° C
