Features of the 8in Subwoofer: Dual 8″ polypropylene cone woofers Large port area for extended low-frequency performance Dual-chamber ported bandpass cabinet Defeatable passive 120 Hz low-pass filter with impedance compensation 250 watts continuous power handling, 700 watts peak 70/100 V multitap transformer with 8 ohm bypass Yoke mount and flying hardware included Marine grade plywood construction Specification: Configuration: Surface mount bandpass subwoofer, ported Low-frequency transducer: Dual 8″ (200 mm) weather resistant, polypropylene cone woofers, rubber surround Frequency range Frequency response (-6 dB): 42 to 165 Hz Useable frequency range (-10 dB): 36 to 205 Hz Filter 120 Hz low-pass, passive, bypassable Maximum output: Calculated peak / continuous Output 2 pi (half space): 124 dB SPL / 118 dB SPL 4 pi (full space): 118 dB SPL / 112 dB SPL Nominal impedance: 8 ohms Continuous power handling: 250 W (2 hours IEC) Recommended max amp power: 500 W (loudspeaker “program” power) Sensitivity: 94 dB, 2.83 V at 1 m, half space (2 pi) Transformers: Type Custom low distortion laminated core, wide bandwidth design Taps 70V: 200, 100, 50, 25 W; 8Ω bypass 100V: 200, 100, 50 W; 8Ω bypass Enclosure Details Material: Marine grade plywood, ABS, steel grille Environmental: Exceeds Mil Spec 810 for humidity, salt spray and dust; IEC 60529 IP-X4 splash rating Finish: Textured black paint Grille: Painted steel Connectors: Four-position barrier strip; 2 in / 2 out Mounting Hardware: Black powder coated steel yoke with attachment hardware Black zinc coated forged shoulder steel M6 eyebolts Black powder coated steel shear plates with attachment hardware Black rubber feet with integral threaded bolt Net Weight 43 lb / 19.5 kg Shipping Weight 55 lb / 25 kg
