Features of the Lab Gruppen 6800 Watt 4 Channel Amplifier 6,800 Watt, 4-channel amplifier with up to 1,700 Watts output per channel and NomadLink network for monitoring and control Selectable gain plus scalable Voltage Peak Limiter (VPL) and bridge-mode operation allow custom configuration for any application 4 x 1,200 Watts into 2 Ohms, 4 x 1,700 Watts into 4 Ohms, 4 x 1,200 Watts into 8 Ohms, 4 x 625 Watts into 16 Ohms, 4 x 1,600 Watts into Hi-Z 70 V, 4 x 1,200 Watts into Hi-Z 100 V Proven and reliable Class-TD output stage delivers Class-A/B audio quality with Class-D efficiency Regulated Switch Mode Power Supply (R.SMPS) ensures constant power output at all times Intuitive DeviceControl software monitors and controls key functions via the NomadLink network Comprehensive protection scheme including current, voltage, DC, temperature, short circuit and open load warnings Efficient Intercooler copper cooling system dissipates more heat for extended peak output 4 x balanced analog audio inputs on 3-pin Phoenix* connectors 4 x barrier strip 2-pole screw terminal output connectors Removable dust filter grille for increased air circulation Compact and durable 2U rackmount chassis saves space in install applications 10-Year Warranty Program* Designed and engineered in Sweden
