Features of the Matrix Mix Engine: For High-Performance Audio Applications Open Architecture DSP Matrix 12 Mic/Line Inputs 8 Line Outputs 8 Configurable GPIOs 24×24 OMNEO/Dante Channels Task Engine for System Control Integrated SONICUE Sound System Software 48/96 kHz Signal Processing, Low Latency Includes Euroblock Connectors Includes Power Cord Specifications: Matrix size – 36 x 32 Sampling rate – 48 kHz /96 kHz Dante in/out – 24/24 Analog inputs – 12 mic/line Analog outputs – 8 Max. input/output level – 22 dBu Signal to noise ratio (inputs/outputs) – > 118 dB Signal processing – 32/40-bit floating point THD N – < 0.002 % Latency (analog in/out, 48 kHz / 96 kHz) – < 0.45 ms / < 0.22 ms Control ports – 8 GPIO Dimensions (WxHxD) – 19.02 x 1.71 x 18.54 Inch / 483 x 43.5 x 471 mm (19″, 1 RU) Weight – 13.2 lbs (6.0 kg)
