The MMA welder -200R is a portable welding system that impresses with its excellent quality, which is specialized for STICK welding! – MMA WELDER – FUNCTIONS MMA STICK welding to 200A. Digital display Digital control of the individual welding parameters Arc-Force / Hot-Start / Anti-Stick Prevents the electrode from sticking Extra light Only 3,5kg – MMA WELDER 200-R – TECHNICAL DATA Processes: MMA / STICK Welding Power supply: 220-240V Open circuit voltage: 64V Frequency: 50/60Hz Mains fuse (slow blow): 15 A Arc-Force / Hot-Start / Anti-Stick Settings: continuous Adjustment range MMA: 20-200A Duty cycle MMA: 200A-60% / 130A-100% Electrode diameter MMA Ø: 1,5 – 5,0mm Weldable materials: steel, stainless steel, aluminum, cast materials Insulation class: B Housing protection degree: IP 21S Dimensions (LxWxH): ca. 290x140x110mm Weight: 3,5kg MMA WELDER 200-R Extra light inverter MMA welder for STICK welding The extra-light (3,5kg) and robust MMA welder is a welding machine that operates on a 230V input power. With this STICK Welder you can perfectly weld materials such as steel, stainless steel, aluminum and cast materials. STICK FUNCTIONS Anti-Stick Prevents the stick electrode from sticking by regulating the current shortly before the short circuit. Arc-Force The welding current is electronically adjusted for different arc lengths. Hot-Start The start of the weld seam is heated more quickly and prevents the stick electrode from sticking when welding starts, which is achieved thanks to the automatic superimposition of the welding current. IGBT Technology The device is equipped with the latest IGBT inverter technology, which guarantees a high duty cycle and stable arc! Digital display On the IPOTOOLS MMA-200R you can continuously determine the current range with one turn of the button, which you can read off the digital display. STICK Welding With the MMA-160R the MMA Stick welding with covered stick electrodes up to 4mm will be no obstacle for you. IPOTOOLS quality! Today, IPOTOOLS equipment is synonymous with many years of experience, continuous development in the field of MIG TIG welders and plasma cutters, as evidenced by thousands of satisfied customers. Take a look at our range of IPOTOOLS equipment, we will be glad to help you with your choice! – IPO Technik-Handels GmbH grants all customers a 7-year guarantee for all welding machines and / or plasma cutters that were purchased directly from IPO Technik-Handels GmbH of the IPOTOOLS brand. You can find warranty conditions here: warranty conditions SCOPE OF DELIVERY 1x Inverter STICK Welder MMA-200R 1x Ground clamp 2m 1x Electrode holder 2m 1x Welding shield 1x Slag hammer with brush 1x Instruction manual
