TIG SYN: Synergic control options in TIG mode set the recommended parameters for you. Adjustments can be made as required.TIG HF or Lift TIG (manual): Set the parameters yourself. Choose TIG welding with HF ignition or Lift TIG.Supplied including XTS910 water cooler with 12-litre tank and TR008 trolley with gas cylinder holder (gas cylinders up to 50L).New feature – TIG Amplitude: The independent amplitude/amp regulation allows the EP and EN amperages to be set separately. This ensures precise control of heat input to the workpiece and electrode. The advanced AC balance controls the amount of oxidation cleaning (the ampere time in EN) which is required for welding high-quality aluminium. The AC frequency determines the width of the arc cone and the strength of the arc.Advanced settings: for more adjustment options.Choice of 4 wave types in AC mode: square wave (standard), soft square wave, trapezoidal wave and sine wave.Spot welding and stitch welding.AC Mix can be set (DC mode)Q start and Q time (DC TIG)Memory function: Saving of 6 welding programmes for fast start-up. Outgoing Current5-315A DC 10-315A ACIncoming Current3 x 400VPulse range0.5 – 200HzUp slope function0-10sDown slope function0-10spre-flow0-10spost-flow0-10sAC Frequency50 – 250HzMinimal Fuse rating16A TKVA13.6IsolationIP23SGenerator Size17KVASize without trolley and cooler580mm x 240mm x 440mmWeight machine (kg)38Duty Cycle TIG315A @ 60% 220A @ 100%Duty Cycle MMA270A @ 70% 210A @ 100%
